Product Recognition

Certification Number

ZC10-20127002

Name

Vesta Shield

Short Description

Vesta is a round the clock smart monitoring solution to protect the people and things that matter the most and help you live life at home or manage your business, better.

Long Description

Vesta is a smart monitoring solution comprising of the Vesta Hub, wireless sensors and a smart plug. Vesta Hub seamlessly connects with the sensors to provide wholesome security experience and peace of mind. Current Vesta ecosystem can monitor home intrusion, room temperature &, illuminance level. All the events and notifications are viewed via the Vesta mobile App (Both Android and iOS). Also, the App could notify emergency contacts about the unmonitored events and even make calls notifying on the status. Vesta Hub is equipped with a back-up battery and 4G LTE SIM to ensure it is active and connected even during power outages.

Brand

Viewqwest Vesta

Product Identifier

SVHSZWB1

Product Line

Shield

OEM Version

HW: 1 FW: 1.02:07.13:02.03

Hardware Platform

ZM5101

Z-Wave Version

6.82.01

Library Type

CONTROLLER_BRIDGE

Device Type

Gateway

Role Type

ROLE_TYPE_CONTROLLER_CENTRAL_STATIC

Manufacturer ID

0x0367

Product Type ID

0x0001

Product ID

0x0001

User Icon

0x0500

Installer Icon

0x0500

Frequency Plans

KR: 920.90MHz, 921.70MHz, 923.10MHz

Categories

Sensors, All Lighting Devices, On/Off Switches/Devices, Security Systems

Countries / Regions

Singapore

Supported Command Classes

Controlled Command Classes

S2 Classes

S2_UNAUTHENTICATED, S2_AUTHENTICATED, S2_ACCESS_CONTROL

Documents

Features

Association Groups

Texts

ID	Description	Value
1	Classic Inclusion	Steps for Performing Classic device inclusion: Step 1: Have the device to be added ready and ensure it has been reset Step 2: Go to MENU --> DEVICE SETUP --> ADD DEVICE Step 3: Press the SCAN button Step 4: Press the ACTION button on the device to be added Step 5: Enter Partial DSK String if adding o S2 Secure mode and Submit Step 6: For S0 and Unsecure devices press the ACTION button and add without DSK Step 7: Choose the device from the list of Available Devices and Click ADD. The device is added and can be renamed
2	Classic Exclusion	Step 1: Go to MENU --> DEVICE SETUP --> REMOVE DEVICE Step 2: Click CONFIRM on the pop-up message Step 3: Make sure you have the device with you and press the REMOVE button and then immediately press the action button on your device Step 4: The device will be removed from the z-wave network and from Vesta. This may take up to 60 seconds. Once the device is removed it will no longer be visible in the Device List.
5	Factory Reset Procedure	Factory Reset: Please use this procedure only when the network primary controller is missing or otherwise inoperable. Factory reset can be performed in 2 ways: 1] Hardware Factory Reset: To reset the hub back to its factory default state, press the reset button (next to the power cycle button) continuously for up to 5 seconds. You will hear a voice prompt to say the factory reset process has started. Then please allow up to 5 minutes for the whole reset process to complete. Once the hub has been reset, you will be notified by another voice prompt at the end to indicate that the reset process has been complete. 2] Factory Reset through APP UI: Step 1: Go to MENU --> SETTINGS --> FACTORY RESET Step 2: Press PROCEED in the reset confirmation dialog box Step 3: Wait for 4 minutes for the reset process to be complete
8	Where to find S2 DSK on product	1] The Security 2 DSK of the Vesta Hub comes with the product packaging as a card which is kept with the user manual 2] Steps to Access DSK on the App UI Step 1: Go to the Menu Step 2: Choose Settings Step 3: Choose Show Hub DSK
6	Other Special Features	NA

Supports NWI

Yes

Supports Explorer Frames

Yes

Radio Range Z-Wave (m)
