COMMAND_CLASS_SENSOR_MULTILEVEL_V5

Sensor Multilevel V5

0x31

5

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi-Channel Association V3

0x8E

3

COMMAND_CLASS_BATTERY

Battery

0x80

1

COMMAND_CLASS_CONFIGURATION

Configuration

0x70

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_VERSION_V2

Version V2

0x86

2

COMMAND_CLASS_WAKE_UP_V2

Wake Up V2

0x84

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_ASSOCIATION_GRP_INFO

Association Group Info

0x59

1

COMMAND_CLASS_MULTI_CHANNEL_V4

Multi-Channel V4

0x60

4

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2

Firmware Update Meta-Data V2

0x7A

2

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

COMMAND_CLASS_NOTIFICATION_V4

Notification V4

0x71

4

COMMAND_CLASS_BASIC

Basic

0x20

1

Manual_Primary_Lang

Product or Owner's Manual

Battery Quantity

Battery Type

Firmware Updatable

IP (Ingress Protection) Rated

Sensors

Supported Notification Types

1

5

0

Lifeline group. 1. The Battery Report or Multilevel Sensor Report (Configurable) can be sent to the associated nodes in group 1. 2. When the water leak is detected, the Notification Report will be send to the associated nodes in group 1. 3. When the Water Sensor is reset, the Device Reset Locally CC will be send to the associated nodes in group 1.

2

5

0

Send the configuration parameter 0x88 to the associated nodes in group 2.

3

5

0

Send Basic Set (configured by parameter 0x58) to the associated nodes in Group 3 when the Sensor probe 1 is triggered.

4

5

0

Send Basic Set (configured by parameter 0x59) to the associated nodes in Group 4 when the Sensor probe 2 is triggered.

2

Enable/Disable waking up for 10 minutes when re-power on (battery mode) the MultiSensor.

Enable/Disable waking up for 10 minutes when re-power on (battery mode) the MultiSensor.

0

1

0

0

0

9

Report the current power mode and the product state for battery power mode

Report the current power mode and the product state for battery power mode. Note: this parameter cannot be used as Set usage.

0

2

0

0

0

10

Set the alarm time for the Buzzer when the sensor is triggered.

Set the alarm time for the Buzzer when the sensor is triggered.

0

4

0

0

101968650

48

Enable/disable the sensor report

Enable/disable the sensor report

0

1

0

0

0

49

Set the upper limit value (overheat).

Set the upper limit value (overheat).

0

4

0

0

68157696

50

Set the lower limit value (under heat)

Set the lower limit value (under heat)

0

4

0

0

20971776

64

Set the default unit of the automatic temperature report in parameter 101-103.

Set the default unit of the automatic temperature report in parameter 101-103.

0

1

0

0

1

84

Get the state of tilt sensor

Get the state of tilt sensor. Note: this is a Get-only parameter.

0

1

0

0

0

86

Enable/ disable the buzzer.

Enable/ disable the buzzer.

0

1

0

0

1

88

To set which value of the Basic Set will be sent to the associated nodes in association Group 3 when the Sensor probe 1 is triggered.

To set which value of the Basic Set will be sent to the associated nodes in association Group 3 when the Sensor probe 1 is triggered.

0

1

0

0

0

89

To set which value of the Basic Set will be sent to the associated nodes in association Group 4 when the Sensor probe 2 is triggered.

To set which value of the Basic Set will be sent to the associated nodes in association Group 4 when the Sensor probe 2 is triggered.

0

1

0

0

0

94

To set which power source level is reported via the Battery CC.

To set which power source level is reported via the Battery CC.

0

1

0

0

0

101

To set what unsolicited report would be sent to the Lifeline group.

To set what unsolicited report would be sent to the Lifeline group.

0

1

0

0

3

111

To set the interval time of sending reports in Report group 1

To set the interval time of sending reports in Report group 1. Note: 1. The unit of interval time is second if USB power. 2. If battery power, the minimum interval time is equal to Wake Up interval set by the Wake Up CC.

0

4

0

0

3600

135

To set which sensor report can be sent when the water leak event is triggered and if the receiving device is a non-multichannel device.

To set which sensor report can be sent when the water leak event is triggered and if the receiving device is a non-multichannel device.

0

1

0

0

1

136

When the parameter 0x87 is set to 2 or 3, it can get the sensor probes’ status through this configuration value.

When the parameter 0x87 is set to 2 or 3, it can get the sensor probes’ status through this configuration value. Note: This parameter is a Get- only parameter.

0

1

0

0

0

201

Temperature sensor calibration

Temperature sensor calibration. Note: 1. High byte is the calibration value. Low byte is the unit (0x00=Celsius, 0x01=Fahrenheit) 2. The calibration value (high byte) contains one decimal point. E.g. if the value is set to 20 (0x1400), the calibration value is 2.0 ℃ (EU/AU version) or if the value is set to 20 (0x1401), the calibration value is 2.0 ℉(US version) 3. The calibration value (high byte) = standard value - measure value. E.g. If measure value =25.3℃ and the standard value = 23.2℃, so the calibration value= 23.2℃ - 25.3℃= -2.1℃ (0xEB). If the measure value =30.1℃ and the standard value = 33.2℃, so the calibration value= 33.2℃ - 30.1℃=3.1℃ (0x1F).

0

2

0

0

1

252

Enable/disable all configuration parameters to be locked

Enable/disable all configuration parameters to be locked.

0

1

0

0

0

255

Reset to factory defaults.

Reset to factory defaults.

0

4

0

0

0

57

Set the recover limit value of temperature sensor.

Note: 1. When the current measurement <= (Upper limit – Recover limit), the upper limit report is enabled and then it would send out a sensor report when the next measurement is more than the upper limit. After that the upper limit report would be disabled again until the measurement = (Lower limit + Recover limit), the lower limit report is enabled and then it would send out a sensor report when the next measurement is less than the lower limit. After that the lower limit report would be disabled again until the measurement >= (Lower limit + Recover limit). 3. High byte is the recover limit value. Low byte is the unit (0x01=Celsius, 0x02=Fahrenheit).

0

2

0

0

5121

2

Exclusion

Turn the primary controller of Z-Wave network into exclusion mode, short press the product’s Action Button that you can find on the product.

1

Inclusion

Turn the primary controller of Z-Wave network into inclusion mode, short press the product’s Action Button that you can find on the product.

5

Factory Reset

Press and hold the Action Button that you can find on the product for 20 seconds and then release. This procedure should only be used when the primary controller is inoperable.

4

Device Wake-Up

Pressing the Action Button once will trigger sending the Wake up notification command. If press and hold the Z-Wave button for 3 seconds, the Water Sensor will wake up for 10 minutes.

6

Additional Special Features

Support ""Over the Air Firmware Updating"" and “Z-Wave Security”.

Heat Alarm

(Refer to parameters): State idle

Water Alarm

(Refer to parameters): State idle

Home Security

(Refer to parameters): State idle

Air temperature

Water flow
