Product Recognition | |
|---|
Certification Number | ZC12-21080294 |
|---|
Name | Water Sensor |
|---|
Short Description | The 700 Series Z-Wave Plus™ XS Water Leak Sensor was designed to detect and report leaks to your Z-Wave™ hub reliably and quickly so you can prevent potential water damage. |
|---|
Long Description | PRODUCT HIGHLIGHTS:
- Quick and reliable water leak alerts sent to your Z-Wave™ hub
- NEW 700 series chip for faster communication and more battery life than ever
- Extra small to fit anywhere
- Powered by a long-lasting single coin battery
- The latest S2 security and SmartStart for secure set-up
- Supports OTA firmware updates
PRODUCT SPECS:
- Model Number: ZSE42
- Power: 1 x CR2032 battery
- Operating Temperature: 32° – 104° F
- Dimensions: 1.9” x 1” x 0.3”
- Range: Up to 130 feet line of sight
- Installation and Use: Indoor or outdoor under eve (can’t be exposed to direct rainfall or sun, a little splash is OK) |
|---|
Brand | Zooz |
|---|
Product Identifier | ZSE42 |
|---|
Product Line | Line A |
|---|
OEM Version | HW: 1 FW: 1.00 |
|---|
Hardware Platform | ZGM130 |
|---|
Z-Wave Version | 7.13.9 |
|---|
Library Type | SLAVE_ENHANCED_232 |
|---|
Device Type | Notification Sensor |
|---|
Role Type | ROLE_TYPE_SLAVE_SLEEPING_REPORTING |
|---|
Manufacturer ID | 0x027A |
|---|
Product Type ID | 0x7000 |
|---|
Product ID | 0xE002 |
|---|
User Icon | 0x0C05 |
|---|
Installer Icon | 0x0C05 |
|---|
Frequency Plans | US: 916.00MHz, 908.40MHz |
|---|
Categories | Sensors |
|---|
Countries / Regions | United States of America |
|---|
Supported Command Classes | Identifier | Name | Key | Version |
|---|
COMMAND_CLASS_CONFIGURATION_V4 | Configuration V4 | 0x70 | 4 | COMMAND_CLASS_POWERLEVEL | Powerlevel | 0x73 | 1 | COMMAND_CLASS_ASSOCIATION_V3 | Association V3 | | 0 | COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V4 | Multi-Channel Association V4 | | 0 | COMMAND_CLASS_INDICATOR_V3 | Indicator V3 | 0x87 | 3 | COMMAND_CLASS_BATTERY | Battery | 0x80 | 1 | COMMAND_CLASS_SENSOR_BINARY_V2 | Sensor Binary V2 | 0x30 | 2 | COMMAND_CLASS_TRANSPORT_SERVICE_V2 | Transport Service V2 | 0x55 | 2 | COMMAND_CLASS_WAKE_UP_V2 | Wake Up V2 | 0x84 | 2 | COMMAND_CLASS_DEVICE_RESET_LOCALLY | Device Reset Locally | 0x5A | 1 | COMMAND_CLASS_ZWAVEPLUS_INFO_V2 | Z-Wave Plus Info V2 | 0x5E | 2 | COMMAND_CLASS_FIRMWARE_UPDATE_MD_V5 | Firmware Update Meta-Data V5 | 0x7A | 5 | COMMAND_CLASS_ASSOCIATION_GRP_INFO_V3 | Association Group Information V3 | 0x59 | 3 | COMMAND_CLASS_NOTIFICATION_V8 | Notification V8 | 0x71 | 8 | COMMAND_CLASS_SECURITY_2 | Security S2 | 0x9F | 1 | COMMAND_CLASS_VERSION_V3 | Version V3 | 0x86 | 3 | COMMAND_CLASS_SUPERVISION | Supervision | 0x6C | 1 | COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2 | Manufacturer Specific V2 | 0x72 | 2 |
|
|---|
S2 Classes | S2_UNAUTHENTICATED, S2_AUTHENTICATED |
|---|
Documents | Category | Description | File |
|---|
Manual_Primary_Lang | Product Manual in English | |
|
|---|
Features | Feature | Values |
|---|
Battery Quantity | | Battery Type | | Color | | Firmware Updatable | Value |
|---|
Updatable by Consumer by RF |
|
|
|---|
Association Groups | Group Number | Maximum Nodes Supported | End Point ID | Group Name | Description |
|---|
2 | 5 | 0 | Group 2 | This device will send a Basic Set command to Group 2 whenever it detects water. The value of the basic set command sent to Group 2 can be adjusted in the advanced settings to customize the sensor’s behavior. | 1 | 3 | 0 | Lifeline | Lifeline. Notification sent back to the hub when a leak is detected and when it's cleared. |
|
|---|
Configuration Parameters | Parameter Number | Name | Description | Format | Size | Min Value | Max Value | Default Value | Parameter Values |
|---|
1 | LED Indicator Mode | Choose whether you'd like the LED indicator to light up when water is detected. | 2 | 1 | 0 | 1 | 1 | From | To | Description |
|---|
0 | 0 | LED indicator doesn't light up when water is detected | 1 | 1 | LED indicator lights up when water is detected |
| 2 | Alarm Clear Delay | Set the delay for a "dry" report to be sent to the hub when water is no longer detected. | 2 | 4 | 0 | 3600 | 0 | From | To | Description |
|---|
0 | 3600 | seconds |
| 3 | Battery Reporting Threshold | Set the battery reporting threshold. | 2 | 1 | 1 | 50 | 10 | | 5 | Group 2 ON/OFF Basic Set Commands | Choose when you'd like the sensor to send on/off basic set commands to Group 2 once the water detection status changes. | 2 | 1 | 0 | 2 | 1 | From | To | Description |
|---|
0 | 0 | Doesn't send basic set commands | 1 | 1 | Sends 0xFF (ON) when water is detected and 0x00 (OFF) when water is no longer detected | 2 | 2 | Sends 0x00 (OFF) when water is detected and 0xFF (ON) when water is no longer detected |
|
|
|---|
Texts | ID | Description | Value |
|---|
8 | Where to find S2 DSK on product | Initiate inclusion (pairing) in the app (or web interface). Not sure how? ask@getzooz.com
If you’re using an S2 hub, it will ask you to enter the DSK PIN or scan the QR code printed on the back cover sticker of the sensor to complete SmartStart inclusion. | 1 | Classic Inclusion | Initiate inclusion (pairing) in the app (or web interface). Not sure how? ask@getzooz.com
While the hub is looking for new devices, click the Z-Wave button 3 times as quickly as possible. The LED indicator will start flashing to confirm inclusion mode and turn off once inclusion is completed. | 2 | Classic Exclusion | 1. Bring the sensor within direct range of your Z-Wave hub.
2. Put the Z-Wave hub into exclusion mode (not sure how to do that? ask@getzooz.com).
3. Click the Z-Wave button 3 times as quickly as possible.
4. Your hub will confirm exclusion and the sensor will disappear from your controller's device list. | 5 | Factory Reset Procedure | When your network’s primary controller is missing or otherwise inoperable, you may need to reset the device to factory settings manually. In order to complete the process, make sure the sensor is powered, then click the Z-Wave button twice and hold it the third time for 10 seconds. The LED indicator will blink continuously. Immediately after, click the Z-Wave button twice more to finalize the reset. The LED indicator will flash 3 times to confirm a successful reset. | 4 | Wake-Up Procedure | The sensor’s wake-up interval is set to 12 hours by default to save battery life. Use the Wake Up Command Class to adjust the interval. Click the Z-Wave button 4 times quickly to wake the sensor up manually. The LED indicator will flash twice to confirm the device is awake. During wake-up, the sensor turns the Z-Wave radio on for one minute to receive communication from the hub. Long wake-up interval will not affect how often the sensor reports to your hub so we recommend leaving the default setting to conserve battery. |
|
|---|
Supported Notification Types | Notification Type | Event / State |
|---|
Water Alarm | (Refer to parameters): State idle | Water Alarm | Sensor status: Water leak detected |
|
|---|
Supports NWI | Yes |
|---|
Supports Explorer Frames | Yes |
|---|
Supports SmartStart | Yes |
|---|
Radio Range Z-Wave (m) | 40 |
|---|
