| 2 | Sensor State Polarity | This parameter defines the polarity of the magnet sensor. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 0 | Closed when Magnet in proximity | | 1 | 1 | Opened when Magnet in proximity |
|
| 8 | BASIC command value sent to 2nd Association Group on ‘Off‘ event | This is the BASIC command value sent in case of ‘Off‘ event. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| -1 | -1 | Value | | 0 | 99 | Value |
|
| 9 | Time Delay of ‘Off‘ command frame | Off command is sent after a delay defined in this parameter. | 0 | 2 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 32400 | seconds |
|
| 10 | Time Delay of ‘Off‘ command frame | Off command is sent after a delay defined in this parameter. | 0 | 2 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 32400 | seconds |
|
| 11 | Delay of Tamper Alarm Cancellation | Time a tamper alarm is delayed. | 0 | 2 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 32400 | seconds |
|
| 7 | BASIC command value sent to 2nd Association Group on ‘On‘ event | This is the BASIC command value sent in case of ‘On‘ event. | 0 | 1 | 0 | 0 | -1 | | From | To | Description |
|---|
| -1 | -1 | Value | | 0 | 99 | Value |
|
| 5 | 2nd Association Group Trigger | his parameter defines the status of the magnet switch that causes sending a BASIC command to all devices of Association Group 2. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 0 | Switch after ‘Open‘ and ‘Close‘ | | 1 | 1 | Switch after ‘Open‘ | | 2 | 2 | Switch after ‘Close‘ |
|
| 6 | Command Sent to Devices of Association Group 2 | This parameter defines which commands is sent to 2nd Association Group | 0 | 1 | 0 | 0 | 2 | | From | To | Description |
|---|
| 0 | 0 | On | | 1 | 1 | Off | | 2 | 2 | On and Off |
|
| 1 | Sensor Operation Mode | This parameter defines if the internal magnet sensor or the external terminal input is detected and used to issue alarm notification. There is always one input active only. The other sensor input the deactivated. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| 1 | 1 | External Terminal Inputs Used | | 0 | 0 | Internal Magnet Sensor Used |
|
| 4 | Range Test after double click | Allows to enable the activation of a Z-Wave range test with double clicking the tamper switch. | 0 | 1 | 0 | 0 | 0 | | From | To | Description |
|---|
| 0 | 0 | Disabled | | 1 | 1 | Enabled |
|
