Product Recognition
Certification Number	ZC10-17055576
Name	Z-Wave Plus Extender
Short Description	The WeR@Home Z-Wave® Plus Extender incorporates third-party Z-Wave® devices into WeR@Home™, integrating home automation and control functions with the core WeR@Home™ system.
Long Description	The WeR@Home Z-Wave® Plus Extender allows you to incorporates third-party smart home devices into WeR@Home using the Z-Wave interoperable, home control, wireless protocol. The Z-Wave Plus Extender connects the WeR@Home hub to a network of smart home devices from a range of manufacturers and allows for full communication and control of those devices. The Z-Wave Plus Extender applies the full power of WeR@Home‎ Smart Rules to control Z-Wave devices by triggering them to perform specific actions, at specific times, and in specific situations. The following Z-Wave device types are supported: - Door locks - On/Off switches - Dimmers - Thermostats - Power strips - Multi-channel devices - Multi-colored RGBW LED bulbs - Multi-input/ multi-output devices - Glass break detector - Garage door controller
Brand	Essence Security
Product Identifier	ES800ZWP_AU_Mxx
OEM Version	HW: 4 FW: 4.33:04.06
Hardware Platform	ZM5101
Z-Wave Version	6.61.00
Library Type	CONTROLLER_STATIC
Device Type	Central Controller
Role Type	ROLE_TYPE_CONTROLLER_CENTRAL_STATIC
Manufacturer ID	0x0160
Product Type ID	0x0001
Product ID	0x0001
User Icon	0x0100
Installer Icon	0x0100
Frequency Plans	ANZ: 919.80MHz, 921.40MHz
Categories	All Controllers, Gateway Controller
Countries / Regions	Australia
Supported Command Classes	Identifier Name Key Version COMMAND_CLASS_POWERLEVEL Powerlevel 0x73 1 COMMAND_CLASS_APPLICATION_STATUS Application Status 0x22 1 COMMAND_CLASS_CRC_16_ENCAP CRC16 Encapsulation 0x56 1 COMMAND_CLASS_SECURITY Security S0 0x98 1 COMMAND_CLASS_VERSION_V2 Version V2 0x86 2 COMMAND_CLASS_DEVICE_RESET_LOCALLY Device Reset Locally 0x5A 1 COMMAND_CLASS_ZWAVEPLUS_INFO_V2 Z-Wave Plus Info V2 0x5E 2 COMMAND_CLASS_ASSOCIATION_V2 Association V2 0x85 2 COMMAND_CLASS_ASSOCIATION_GRP_INFO Association Group Info 0x59 1 COMMAND_CLASS_MANUFACTURER_SPECIFIC Manufacturer Specific 0x72 1
Controlled Command Classes	Identifier Name Key Version COMMAND_CLASS_DOOR_LOCK Door Lock 0x62 1 COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3 Multi-Channel Association V3 0x8E 3 COMMAND_CLASS_BATTERY Battery 0x80 1 COMMAND_CLASS_THERMOSTAT_FAN_STATE Thermostat Fan State 0x45 1 COMMAND_CLASS_SWITCH_BINARY Switch Binary 0x25 1 COMMAND_CLASS_BASIC Basic 0x20 1 COMMAND_CLASS_CRC_16_ENCAP CRC16 Encapsulation 0x56 1 COMMAND_CLASS_SECURITY Security S0 0x98 1 COMMAND_CLASS_THERMOSTAT_FAN_MODE_V3 Thermostat Fan Mode V3 0x44 3 COMMAND_CLASS_THERMOSTAT_MODE_V2 Thermostat Mode V2 0x40 2 COMMAND_CLASS_THERMOSTAT_SETPOINT_V2 Thermostat Setpoint V2 0x43 2 COMMAND_CLASS_WAKE_UP_V2 Wake Up V2 0x84 2 COMMAND_CLASS_SWITCH_MULTILEVEL_V3 Switch Multilevel V3 0x26 3 COMMAND_CLASS_ASSOCIATION_V2 Association V2 0x85 2 COMMAND_CLASS_MULTI_CHANNEL_V4 Multi-Channel V4 0x60 4 COMMAND_CLASS_MANUFACTURER_SPECIFIC Manufacturer Specific 0x72 1
Documents	Category Description File Manual_Primary_Lang Product or Owner's Manual ESUGSL015 WeR@Home Z-Wave User Guide Rev 1.4.2 (rel 4.6 certification).pdf
Features	Feature Values Communications Connections Value RS-232 (Serial) Color Value White Gateway Has Preferred Partners Switch Load Capacity Current Value 1Amp Switch Load Capacity Volt-Ampere Value 5Volt Supported Notification Types Value System
Association Groups	Group Number Maximum Nodes Supported End Point ID Description 1 3 0 Z-Wave Plus Lifeline. Lifeline Notification Reports - Device Reset Locally (Notification sent when device is reset to factory)
Texts	ID Description Value 5 Factory Reset Restoring factory settings returns your Z-Wave Plus Extender to its default settings and removes Z-Wave device definitions. Please use this procedure only when the network primary controller is missing or otherwise inoperable. To restore factory settings: 1. Tap . The main menu appears. 2. Tap Settings. The Settings menu appears. Tap Z-Wave. The Z-Wave screen appears. Tap Reset to Factory. 24 Controller Exclusion You can remove a Z-Wave device from WeR@Home™ if the device is not needed, becomes unresponsive, or becomes disconnected from the network. To remove a Z-Wave device: 1. Log in to the WeR@Home™ app.Managing Your Z-Wave Devices WeR@Home™ Z-Wave® User Guide 15 2. Tap . The main menu appears. 3. Tap DEVICES. The Devices screen appears. 4. Tap DELETE in the top right-hand corner of the screen. 5. Tap for the device that you want to remove. The Remove Z-Wave Device window appears. 6. Press the pairing button on the Z-Wave device, according the device’s documentation, and tap OK in the window. 7. Tap OK in the top right-hand corner of the screen. 23 Controller Inclusion After you install a Z-Wave Extender, you can add a Z-Wave device to WeR@Home™. Install the device within 20 m (65.6 ft.) of the Z-Wave Extender. Use Z-Wave devices with repeater capabilities to extend network range. Before you begin, refer to the device’s documentation to learn the pairing process for the specific device. To add a Z-Wave device: 1. Log in to the WeR@Home™ app. 2. Tap . The main menu appears. 3. Tap DEVICES. The Devices screen appears. 4. Tap ""Add new device"". The Add New Devices screen appears displaying a list of the available device types including the Z-Wave device types. 5. Select the type of Z-Wave device to be added. The Power your device window appears. 6. Position the Z-Wave device within 0.5 m (1.6 ft.) of the Z-Wave Extender. 7. Insert batteries into the device or connect to the nearest power outlet. The Step 1 of 2 pairing screen appears. 3 Learn Mode (adding another controller) If you have an existing third-party Z-Wave network, WeR@Home™ can join the network. WeR@Home™ enters ""learn"" mode on the existing network to automatically copy the existing network's Smart Home network structure. When you join a Z-Wave network, you have access to the Z-Wave devices supported by WeR@Home™. The Z-Wave Plus Extender is assigned one of the following roles depending on the third-party controller capabilities: Secondary (inclusion) - allowed to add or delete additional Z-Wave devices Secondary –not allowed to add or delete additional Z-Wave devices To join an existing third-party Z-Wave network: 1. Remove all Z-Wave devices from your WeR@Home™, except for your Z-Wave Plus Extender. Refer to ‎5.5 Removing a Z-Wave Device on page 15. 2. In the WeR@Home™ app, tap . The main menu appears. 3. Tap Devices. The Devices screen appears. 4. Tap for your Z-Wave Plus Extender. The Z-Wave Controller configuration screen appears. 5. Put the primary controller of the existing network into Add mode, according to the controller’s user manual. 6. Tap Join Existing Network. All Z-Wave devices are removed from WeR@Home™. WeR@Home™ copies the topology of the existing network and prompts you to enter the name for the existing network controller. 7. Enter the name for the existing network controller and tap OK.
Supports NWI	Yes
Supports Explorer Frames	Yes
