Product Recognition | |
|---|---|
Certification Number | ZC10-19086718 |
Name | Z-Wave Range Extender Repeater |
Short Description | The Range Extender Repeater is a Z-Wave™ enabled device (interoperable, two-way RF mesh networking technology) and is fully compatible with any Z-Wave™enabled network. |
Long Description | The Range Extender Repeater is a Z-Wave™ enabled device (interoperable, two-way RF mesh networking technology) and is fully compatible with any Z-Wave™enabled network. Every main powered Z-Wave enabled device acts as a signal repeater and multiple devices result in more possible transmission routes which
helps eliminate “RF dead-sports” Z-Wave™ enabled devices displaying the Z-Wave™ logo can also be used with it regardless of the manufacturer, and ours can
also be used in other manufacturer’s Z-Wave™ enabled networks.
The product supports Over The Air(OTA) feature for the products firmware upgrade. |
Brand | Philio Technology |
Product Identifier | PAU05 |
Product Line | Philio Z-Wave Products |
OEM Version | HW: 1 FW: 1.01 |
Hardware Platform | SD3502 |
Z-Wave Version | 6.81.03 |
Library Type | SLAVE_ENHANCED_232 |
Device Type | Repeater |
Role Type | ROLE_TYPE_SLAVE_ALWAYS_ON |
Manufacturer ID | 0x013C |
Product Type ID | 0x000C |
Product ID | 0x0074 |
User Icon | 0x1B00 |
Installer Icon | 0x1B00 |
Frequency Plans | EU: 869.85MHz, 868.40MHz |
Categories | Network Devices |
Countries / Regions | European Union |
Supported Command Classes | |
S2 Classes | S2_UNAUTHENTICATED |
Documents | |
Features | |
Association Groups | |
Texts | |
Supports NWI | Yes |
Supports Explorer Frames | Yes |
Supports SmartStart | Yes |
Radio Range Z-Wave (m) | 40 |
