Product Recognition | |
|---|---|
Certification Number | ZC10-20016827 |
Name | Z-Wave Relay Dimmer switch |
Short Description | This product is a Z-Wave multi-channel device.With dimming and relay two different functions. |
Long Description | This product is a Z-Wave multi-channel device.With dimming and relay two different functions. Built-in S2 security encryption |
Brand | Zooz |
Product Identifier | ZW34 |
Product Line | Linen A |
OEM Version | HW: 2 FW: 1.00 |
Hardware Platform | ZM5202 |
Z-Wave Version | 6.82.00 |
Library Type | SLAVE_ENHANCED_232 |
Device Type | Light Dimmer Switch |
Role Type | ROLE_TYPE_SLAVE_ALWAYS_ON |
Manufacturer ID | 0x0312 |
Product Type ID | 0xa000 |
Product ID | 0xa008 |
User Icon | 0x0604 |
Installer Icon | 0x0600 |
Frequency Plans | US: 916.00MHz, 908.40MHz |
Categories | All Lighting Devices, Dimming Lighting Devices, On/Off Switches/Devices, Lighting Accessories |
Countries / Regions | United States of America |
Supported Command Classes | |
Controlled Command Classes | |
S2 Classes | S2_UNAUTHENTICATED |
Documents | |
Features | |
Association Groups | |
Configuration Parameters | |
Texts | |
Supports NWI | Yes |
Supports Explorer Frames | Yes |
Radio Range Z-Wave (m) | 40 |
