Product Recognition | |
|---|---|
Certification Number | ZC10-20076940 |
Name | Z-Wave Repeater with socket iO |
Short Description | Smart Plug is a Z-Wave Switch plugin module specifically used to enable Z-Wave command and control (on/off) of any plug-in tool. |
Long Description | Smart Plug is a Z-Wave Switch plugin module specifically used to enable Z-Wave command and control (on/off) of any plug-in tool. It can report wattage consumption or kWh energy usage.
This device is a security enabled Z-Wave Plus product that is able to use encrypted Z-Wave Plus messages to communicate to other security enabled Z-Wave Plus products.
Smart Plug is also a security Z-Wave device and supports the Over The Air (OTA) feature for the product’s firmware upgrade.
This device must be used in conjunction with a Security Enabled Z-Wave Controller in order to fully utilize all implemented functions.
Features:
1) AC output switch on/off by manual or Z-Wave command;
2) RGB LED indicates the Z-WAVE network range and load power;
3) Support S0 and S2 security network;
4) Supporting power meter;
5) Supporting repeater role;
6) Supporting firmware OTA;
7) Supporting Smart Start;
8) Supports over-current protection |
Brand | Simon |
Product Identifier | 10002880-039 |
Product Line | 5P |
OEM Version | HW: 1 FW: 1.02 |
Hardware Platform | ZM5202 |
Z-Wave Version | 6.81.01 |
Library Type | SLAVE_ENHANCED_232 |
Device Type | On/Off Power Switch |
Role Type | ROLE_TYPE_SLAVE_ALWAYS_ON |
Manufacturer ID | 0x0208 |
Product Type ID | 0x0100 |
Product ID | 0x0019 |
User Icon | 0x0700 |
Installer Icon | 0x0700 |
Frequency Plans | EU: 869.85MHz, 868.40MHz |
Categories | All Lighting Devices, On/Off Switches/Devices |
Countries / Regions | European Union |
Supported Command Classes | |
S2 Classes | S2_UNAUTHENTICATED |
Documents | |
Features | |
Association Groups | |
Configuration Parameters | |
Texts | |
Supported / Controlled Meter Types | |
Supports NWI | Yes |
Supports Explorer Frames | Yes |
Supports SmartStart | Yes |
Radio Range Z-Wave (m) | 40 |
