Product Recognition
Certification Number	ZC10-15030002
Name	Z-Wave+ Smart Plug ON/OFF (Type E)
Short Description	Smart Plug Z-Wave Plus® compliant for ON/OFF switching. Can control a load up to 3500W (resistive) and notify gateway in case of Power outage.
Long Description	The NodOn Smart Plug can be controlled by any kind of Z-Wave® (or Z-Wave Plus®) gateway or other Z-Wave® controller (standalone mode) such as the NodOn® Soft Remote or Octan Remote. In both standard, Type E (French) or Schuko (German), the plug can be mounted in both side (head up or head down). Combined to its ultra-thin design, these both specificities allow an easy integration, without obstructing nearby power holes on a power strip. Equipped with a very small super-capacitor, the NodOn Smart Plug is able to send an emergency frame to the gateway in case of power outage. The NodOn Smart Plug is based on brand new 500 series Z-Wave® module from Sigma Designs®, and support all the new features of Z-Wave Plus® standard: Longer range (up to 40m), lower power consumption, higher data rate transmission, and many more new features.
Brand	NodOn
Product Identifier	ASP-3-1-00
OEM Version	01
Hardware Platform	ZM5202
Z-Wave Version	6.51.02
Library Type	SLAVE_ENHANCED_232
Device Type	On/Off Power Switch
Role Type	ROLE_TYPE_SLAVE_ALWAYS_ON
Manufacturer ID	0x0165
Product Type ID	0x0001
Product ID	0x0001
Frequency Plans	EU: 869.85MHz, 868.40MHz
Categories	All Lighting Devices, On/Off Switches/Devices
Countries / Regions	European Union
Documents	Category Description File Manual_Primary_Lang Product or Owner's Manual NodOn_SmartPlug_ZWave_UserGuide_EN.pdf
Association Groups	Group Number Maximum Nodes Supported End Point ID Description 6 5 0 Power Failure Set OFF When the Smart Plug detects a power outage, it sets OFF the associated devices in the group. 7 5 0 Power Recover Set ON When the Smart Plug detects a Power Recover, it will switched ON the associated devices in the group. 8 5 0 Power Recover Set OFF When the Smart Plug detects a Power Recover, it will switched OFF the associated devices in the group. 1 5 0 Z-Wave Plus® Lifeline This group is generally used to report information of the Smart Plug to the Main Controller of the network. 2 5 0 Follow State When the Smart Plug is switched ON (respectively OFF) - either locally or by wireless - it will send ON (respectively OFF) command to the associated devices in the group. 3 5 0 Follow Complementary State When the Smart Plug is switched ON (respectively OFF) - either locally or by wireless - it will send OFF (respectively ON) command to the associated devices in the group. 4 5 0 Power Failure Notification When the Smart Plug detects a power outage or a recover of power, it sends to following command to associated devices in the group. Detected = Power Management - AC disconnected Recovered = Power Management - AC re-connected 5 5 0 Power Failure Set ON When the Smart Plug detects a power outage, it sets ON the associated devices in the group.
Configuration Parameters	Parameter Number Name Description Format Size Min Value Max Value Default Value Parameter Values 1 DEFAULT STATE This parameter defines the status of the Smart Plug after a Power Failure or after being plugged. 0 1 0 0 2 From To Description 0 0 ON 1 1 OFF 2 2 Status before power outage 4 ALWAYS ON This parameter forces the Smart Plug status to be ON. While enable it is not possible to switch OFF the plug (local or wireless). 0 1 0 0 0 From To Description 0 0 Always ON disable 1 1 Always ON enable 3 FOLLOW STATE This parameter allows to enable or deactivate Group 2 & Group 3. The value may be the sum of available values. For example, if you want to enable Group 2 & 3, the parameter value is 1+2=3. 0 1 0 0 3 From To Description 0 0 Group 2 and Group3 Disable 1 1 Group 2 Enable 2 2 Group 3 Enable 5 Alarm 1 Type Configuration This parameter is to set the Alarm 1 Type Configuration. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need. (Notification type, Event type, Priority, Lock device, Group 2 Enable, Group 3 Enable, Alarm Action, LED behavior, Alarm duration) 0 2 0 0 0 From To Description 0 65535 To set-up your values please follow this link : www.nodon.fr/support/asp3/alarm 6 Alarm 1 Specifications This parameter is to set the Alarm 1 Specifications. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need. 0 4 0 0 0 From To Description 0 2097151999 To set-up your values please follow this link : www.nodon.fr/support/asp3/alarm 7 Alarm 2 Type Configuration This parameter is to set the Alarm 2 Type Configuration. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need. (Notification type, Event type, Priority, Lock device, Group 2 Enable, Group 3 Enable, Alarm Action, LED behavior, Alarm duration) 0 2 0 0 0 From To Description 0 65535 To set-up your values please follow this link : www.nodon.fr/support/asp3/alarm 8 Alarm 2 Specifications This parameter is to set the Alarm 2 Specifications. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need. 0 4 0 0 0 From To Description 0 2097151999 To set-up your values please follow this link : www.nodon.fr/support/asp3/alarm 9 Alarm 3 Type Configuration This parameter is to set the Alarm 3 Type Configuration. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need. (Notification type, Event type, Priority, Lock device, Group 2 Enable, Group 3 Enable, Alarm Action, LED behavior, Alarm duration) 0 2 0 0 0 From To Description 0 65535 To set-up your values please follow this link : www.nodon.fr/support/asp3/alarm 10 Alarm 3 Specifications This parameter is to set the Alarm 3 Specifications. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need. 0 4 0 0 0 From To Description 0 2097151999 To set-up your values please follow this link : www.nodon.fr/support/asp3/alarm 11 Alarm 4 Type Configuration This parameter is to set the Alarm 4 Type Configuration. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need. (Notification type, Event type, Priority, Lock device, Group 2 Enable, Group 3 Enable, Alarm Action, LED behavior, Alarm duration) 0 2 0 0 0 From To Description 0 65535 To set-up your values please follow this link : www.nodon.fr/support/asp3/alarm 17 Alarm 7 Type Configuration This parameter is to set the Alarm 7 Type Configuration. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need. (Notification type, Event type, Priority, Lock device, Group 2 Enable, Group 3 Enable, Alarm Action, LED behavior, Alarm duration) 0 2 0 0 0 From To Description 0 65535 To set-up your values please follow this link : www.nodon.fr/support/asp3/alarm
Texts	ID Description Value 1 Inclusion Long press during 2 seconds to send several NIF during 30 seconds or a triple press to send a single NIF 2 Exclusion Long press during 2 seconds to send several NIF during 30 seconds or a triple press to send a single NIF 5 Factory Reset Long press during more than 5 seconds then release. Please use this procedure only when the primary controller is missing or otherwise inoperable. 6 Additional Special Features Power outage / Power recover detection: The product is equipped with a small super-capacitor, allow to send an emergency frame in case of power outage Alarm priority management (check user guide for full details)
Supports NWI	Yes
Supports Explorer Frames	Yes
