COMMAND_CLASS_CONFIGURATION_V4

Configuration V4

0x70

4

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi-Channel Association V3

0x8E

3

COMMAND_CLASS_INDICATOR_V3

Indicator V3

0x87

3

COMMAND_CLASS_BATTERY

Battery

0x80

1

COMMAND_CLASS_APPLICATION_STATUS

Application Status

0x22

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_TRANSPORT_SERVICE_V2

Transport Service V2

0x55

2

COMMAND_CLASS_WAKE_UP_V2

Wake Up V2

0x84

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V5

Firmware Update Meta-Data V5

0x7A

5

COMMAND_CLASS_ASSOCIATION_GRP_INFO_V3

Association Group Information V3

0x59

3

COMMAND_CLASS_NOTIFICATION_V8

Notification V8

0x71

8

COMMAND_CLASS_SECURITY_2

Security S2

0x9F

1

COMMAND_CLASS_SENSOR_MULTILEVEL_V11

Sensor Multilevel V11

0x31

11

COMMAND_CLASS_VERSION_V3

Version V3

0x86

3

COMMAND_CLASS_SUPERVISION

Supervision

0x6C

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

Manual_Primary_Lang

Product Manual in English

Battery Quantity

Battery Type

Color

Firmware Updatable

1

3

0

Lifeline

Lifeline communication from the sensor back to the hub with notifications and multilevel sensor reports.

2

5

0

Group 2

Basic set reports sent to Group 2 when motion is detected.

1

Temperature Scale

Use this parameter to switch from Fahrenheit to Celsius scale.

2

1

0

1

0

4

Light Reporting Threshold

Use it to choose light percentage change to be reported by the sensor.

2

1

5

50

25

6

Motion Sensitivity Level

Use it to adjust PIR sensor sensitivity, where 1 = very high sensitivity and 7 = very low sensitivity.

2

1

1

7

4

7

LED Indicator Mode

Use it to choose between LED indicator modes.

2

1

1

3

3

8

Retry Count

Set 0~10 Retry Count, default:3

2

1

0

10

3

8

Where to find S2 DSK on product

Under the back cover of the sensor.

1

Classic Inclusion

Initiate inclusion (pairing) in the app (or web interface). Click the Z-Wave button with a paperclip twice. The LED indicator will start flashing.

2

Classic Exclusion

Initiate exclusion in the app (or web interface). Click the Z-Wave button with a paperclip twice. The LED indicator will start flashing.

4

Wake-Up Procedure

The sensor’s wake-up interval is set to 12 hours by default to save battery life. You can change the wake-up interval using your controller’s advanced settings if available. During wake-up, the sensor receives communication from the hub (setting updates or network information). Long wake-up interval will not affect how o􀆞en the sensor reports motion and other values to your gateway controller. MANUAL WAKE-UP Press and release the Z-Wave button once to wake the device up. The LED indicator will flash once (blue or orange). You may need to wake the sensor up manually IF: 1. It doesn’t fully configure during set-up (values are not displayed or errors pop up in your hub’s interface). 2. You change advanced settings for the sensor and want them to update.

5

Factory Reset Procedure

If your primary controller is missing or inoperable, you may need to reset the device to factory settings. To complete the reset process manually, remove the back cover to trigger tamper switch. Press and release the Z-Wave button using a paperclip 10 TIMES quickly (within 10 seconds).

Home Security

(Refer to parameters): State idle

Home Security

Cover status: Tampering, product cover removed

Home Security

Motion sensor status: Motion detection

Air temperature

Illuminance

Humidity
