COMMAND_CLASS_CONFIGURATION_V4

Configuration V4

0x70

4

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi-Channel Association V3

0x8E

3

COMMAND_CLASS_INDICATOR_V3

Indicator V3

0x87

3

COMMAND_CLASS_BATTERY

Battery

0x80

1

COMMAND_CLASS_APPLICATION_STATUS

Application Status

0x22

1

COMMAND_CLASS_SECURITY

Security S0

0x98

1

COMMAND_CLASS_SENSOR_BINARY_V2

Sensor Binary V2

0x30

2

COMMAND_CLASS_TRANSPORT_SERVICE_V2

Transport Service V2

0x55

2

COMMAND_CLASS_WAKE_UP_V2

Wake Up V2

0x84

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_ASSOCIATION_V2

Association V2

0x85

2

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V5

Firmware Update Meta-Data V5

0x7A

5

COMMAND_CLASS_ASSOCIATION_GRP_INFO_V3

Association Group Information V3

0x59

3

COMMAND_CLASS_NOTIFICATION_V8

Notification V8

0x71

8

COMMAND_CLASS_SECURITY_2

Security S2

0x9F

1

COMMAND_CLASS_VERSION_V3

Version V3

0x86

3

COMMAND_CLASS_SUPERVISION

Supervision

0x6C

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2

Manufacturer Specific V2

0x72

2

Manual_Primary_Lang

Product Manual

Manual_English

Product Manual in English

Adv_Manual

Advanced Information Product Manual

Color

Firmware Updatable

Battery Quantity

Battery Type

2

5

0

On/Off control (Access)

0x7106

Issue Basic Set when Maqnet is away or near. (The Basic Set Value is determined by Confiquration Parameter 3)

1

5

0

Lifeline

0x0001

Lifeline group. (1) Device Reset Locally Notification: Issued when Factory Reset is performed. (2) Battery Report: lssued periodically to report the current battery level; lssued when battery becomes low. (3) Sensor Binary Report: Issued when Magnet is away or near. (4) Notification Report (Type=0x06; Event=0x16): Issued when sensor state is changed to be Open Status. (5) Notification Report (Type=0x06; Event=0x17): Issued when sensor state is changed to be Close Status. (6) Notification Report (Type=0x08; Event-0x01): Issued when battery voltage change exceeds 20%. (7) Notification Report (Type-0x09; Event=0x04; Param=0x55): Issued when reset due to Watch-Dog Timeout.

2

Sensor Reports

Reverse Sensor Reports (both Sensor Binary Report and Notification Report.)

2

1

0

1

0

Warning: Undefined variable $field_object in /nas/content/live/zwaprodcatalog/wp-content/themes/hello-elementor-child/single-z-wave-product.php on line 98

From	To	Description
0	0	Open Status when Magnet is away, Close Status when magnet is near.
1	1	Close Status when Magnet is away, Open Status when magnet is near.

101

Timed battery report

Set how often battery is reported in minutes.

2

2

1

14400

70

81

Led Indicator

Control LED Indicator. Determine whether the LED flash or not when sending Basic Set, Sensor Binary Report, Notification Report (Access Control) or Wake Up Notification.

2

1

0

3

3

1

Binary Sensor Report

Enable/Disable Binary Sensor Report. Allow for backward compatibility to report Binary if Notification Report cannot be use for status changes.

2

1

0

1

0

4

Application Layer Retry

Configure retry number and wait time. The device supports an application retry mechanism when the application of the device has detected a transmission error when Basic Set, Sensor Binary Report or Notification Report (Access Control) message is sent out but fails to result in an ACK or a Supervision Report.

2

2

0

1535

0

Yes

3

Association Group 2 Settings

Configure the Basic Set value. Determine the Basic Set value to control other Z-Wave devices directly when Magnet is away or near.

2

1

0

6

1

8

Where to find S2 DSK on product

QR/PIN can be found at the bottom of the product. A full DSK string can be found when you open the packaging on the Aeotec Logo Side. Please cut it out of the packaging and write some memo on its backside. Keep it in a safe place.

5

Factory Reset Procedure

If the primary controller is missing or inoperable, you may need to reset the product to factory settings. 1. Make sure the product is powered. 2. Press and hold the Action Button for at least 20s, and release when LED becomes solid red color, then Factory Reset is performed. 3. Wait for the LED indicator to be slow fade-in fade-out red LED color, which indicates the reset operation is successful. Otherwise, please try again. Contact us for further support if needed. Note: 1. This procedure should only be used when the primary controller is missing or inoperable. 2. Factory Reset will: (a) Remove the product from Z-Wave network; (b) Delete the Association setting; (c) Restore the configuration settings to the default.

2

Classic Exclusion

1. Set your main controller into its 'remove product' mode. Refer to its manual if you are unsure of how to perform. 2. Make sure the product is powered. 3. Single-click the Action Button; its red LED will flash for a few seconds. 4. Confirm the removing result. Successful removing can be confirmed by your controller’s message or the LED status. If the removing is successful, LED will change to the default unpaired state which is slow fade-in fade-out red color. If its LED extinguish without slow fade-in fade-out red color, it indicates the removing is unsuccessful. Repeat the above steps or contact us for further support if needed.

1

Classic Inclusion

1. Press the sensor latch with a slotting screwdriver to remove the lid of the sensor. 2. Squeeze the sides of the sensor casing to alleviate pressure on the chipboard; slide the chipboard out. 3. Remove the Pull Tab to engage the pre-installed battery. The sensor’s LED will fade the color red in and out for a few seconds to indicate that it’s powered on. 4. To add the product to your automation network manually: (a) Set your main controller into its 'add product' mode. Refer to its manual if you are unsure of how to perform. (b) Single-click the Action Button; its red LED will flash for a few seconds. (c) If your controller supports S2 security, and you want to add the product into S2 Authenticated network, please scan the QR code or enter the PIN code (the underlined 5-digits of the DSK) when prompted. [IMPORTANT] QR/PIN can be found at the bottom of the product. A full DSK string can be found when you open the packaging on the Aeotec Logo Side. Please cut it out of the packaging and write some memo on its backside. Keep it in a safe place. (d) Wait for the adding process to end. (e) Confirm the adding result. Successful adding can be confirmed by your controller’s message or the LED status. If adding is successful, LED will become solid red color for 10 minutes and then off, or goes into sleep immediately if receiving the Wake Up No More Information from the controller. If its LED goes back to slow fade-in fade-out red color for 10 seconds, it indicates adding is unsuccessful. The product will auto-reset and then activate SmartStart. Repeat the above steps or contact us for further support if needed. 6. Squeeze the sides of the sensor casing lightly again and re-insert the chipboard as it was. Re-attach the lid. 7. Recessed Door Sensor 7 is now a part of your Z-Wave home control system. You can configure it and its automations via your Z-Wave system; please refer to your software's user guide for precise instructions.

4

Wake-Up Procedure

1. Make sure the product is powered. 2. Press and hold the Action Button for at least 2s and release when the LED becomes slow pulsing red color, then Wake Up Notification is issued. 3. Wake Up destination is according to the Wake Up Interval Set. It will stay awake for 10 minutes after issuing Wake Up Notification, that is called 10-Minutes Awake Mode, however it will go into sleep immediately if receives Wake Up No More Information by the Wake Up destination. If you want to exit the 10-Minutes Awake Mode manually, please single-click the Action Button, then it will go into sleep immediately and its LED will extinguish. Note: There is another way to manually trigger Wake Up, that is repower on, but it’s not recommended for inconvenience. The Wake Up destination is according to the Wake Up Interval Set. The Wake Up period starts when the node issues a Wake Up Notification and it ends either 10 seconds after the last received/transmitted frame or at the reception of a Wake Up No More Information Command by the Wake Up destination.

Access Control

Door state: Window/door is open

Access Control

Door state: Window/door is closed

Power Management

Power status: Power has been applied

System

SW status: System software failure (manufacturer proprietary failure code provided)
