10 | LED frame – power limit | This parameter determines maximum active power. Exceeding it results in the LED frame flashing violet. Function is active only when parameter 11 is set to 8 or 9. | 0 | 4 | 0 | 0 | 36800 | From | To | Description |
|---|
500 | 36800 | (50.0-3680.0W, step 0.1W) – power threshold |
|
3 | Second channel – overload safety switch | This function allows to turn off the controlled device in case of exceeding the defined power. Controlled device can be turned back on via button or sending a control frame. | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | function disabled | 10 | 36200 | (1.0-3620.0W, step 0.1W) – power threshold |
|
24 | Buttons orientation | This parameter allows reversing the operation of the buttons. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | default (1st button controls 1st channel, 2nd button controls 2nd channel) | 1 | 1 | reversed (1st button controls 2nd channel, 2nd button controls 1st channel) |
|
60 | Power reports – include self-consumption | This parameter determines whether the power measurements should include power consumed by the device itself. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | Self-consumption not included | 1 | 1 | Self-consumption included |
|
65 | Energy reports for first channel – on change | This parameter defines minimal change (from the last reported) in measured energy that results in sending new report. | 0 | 2 | 0 | 0 | 10 | From | To | Description |
|---|
0 | 0 | reporting on change disabled | 1 | 500 | (0.01-5kWh, 0.01kWh step) – minimal change |
|
67 | Energy reports for second channel – on change | This parameter defines minimal change (from the last reported) in measured energy that results in sending new report. | 0 | 2 | 0 | 0 | 10 | From | To | Description |
|---|
0 | 0 | reporting on change disabled | 1 | 500 | (0.01-5kWh, 0.01kWh step) – minimal change |
|
150 | First channel – operating mode | This parameter allows to choose operating for the 1st channel . | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | delayed OFF | 2 | 2 | single pulse | 0 | 0 | standard operation |
|
151 | Second channel – operating mode | This parameter allows to choose operating for the 2nd channel. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | standard operation | 1 | 1 | delayed OFF | 2 | 2 | single pulse |
|
152 | First channel - reaction to switch for delayed OFF / pulse modes | This parameter determines how the device in timed mode reacts to pushing the button for 1st channel. The parameter is relevant only for button toggles modes (parameter 20 set to 1 or 3). | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | cancel mode and set default state | 1 | 1 | no reaction - mode runs until it ends | 2 | 2 | reset timer - start counting from the beginning |
|
153 | Second channel - reaction to switch for delayed OFF / pulse modes | This parameter determines how the device in timed mode reacts to pushing the button for 2nd channel. The parameter is relevant only for button toggles modes (parameter 20 set to 1 or 3). | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | cancel mode and set default state | 1 | 1 | no reaction - mode runs until it ends | 2 | 2 | reset timer - start counting from the beginning |
|
154 | First channel - time parameter for delayed OFF / pulse modes | This parameter allows to set time parameter used in timed modes for 1st channel (parameter 150). Delay time for switching off or duration of the pulse. | 0 | 2 | 0 | 0 | 50 | From | To | Description |
|---|
0 | 0 | 0.1 second | 1 | 32000 | (1-32000s, 1s step) – time parameter |
|
156 | First channel – Switch ON value sent to 2nd and 3rd association groups | This parameter defines value sent with Switch ON command to devices associated in 2nd and 3rd association group for manual changes of Endpoint 1 state. | 0 | 2 | 0 | 0 | 255 | From | To | Description |
|---|
0 | 99 | 2nd association group | 255 | 255 | 3rd association group |
|
158 | First channel – Double Click value sent to 2nd and 3rd association groups | This parameter defines value sent with Double Click command to devices associated in 2nd and 3rd association group for manual changes of Endpoint 1 state. | 0 | 2 | 0 | 0 | 99 | From | To | Description |
|---|
0 | 99 | 2nd association group | 255 | 255 | 3rd association group |
|
159 | Second channel – Switch ON value sent to 4th and 5th association groups | This parameter defines value sent with Switch ON command to devices associated in 4th and 5th association group for manual changes of Endpoint 2 state. | 0 | 2 | 0 | 0 | 255 | From | To | Description |
|---|
0 | 99 | 4th association group | 255 | 255 | 5th association group |
|
160 | Second channel – Switch OFF value sent to 4th and 5th association groups | This parameter defines value sent with Switch OFF command to devices associated in 4th and 5th association group for manual changes of Endpoint 2 state. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 99 | 4th association group | 255 | 255 | 5th association group |
|
161 | Second channel – Double Click value sent to 4th and 5th association groups | This parameter defines value sent with Double Click command to devices associated in 4th and 5th association group for manual changes of Endpoint 2 state. | 0 | 2 | 0 | 0 | 99 | From | To | Description |
|---|
0 | 99 | 4th association group | 255 | 255 | 5th association group |
|
157 | First channel – Switch OFF value sent to 2nd and 3rd association groups | This parameter defines value sent with Switch OFF command to devices associated in 2nd and 3rd association group for manual changes of Endpoint 1 state. | 0 | 2 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 99 | 2nd association group | 255 | 255 | 3rd association group |
|
1 | Remember device state | This parameter determines how the device will react in the event of power supply failure (e.g. power outage). The parameter is not relevant for outputs set to pulse mode (parameter 150/151 set to 2). | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | remains switched off after restoring power | 1 | 1 | restores remembered state after restoring power |
|
2 | First channel – overload safety switch | This function allows to turn off the controlled device in case of exceeding the defined power. Controlled device can be turned back on via button or sending a control frame. | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
10 | 36200 | (1.0-3620.0W, step 0.1W) – power threshold | 0 | 0 | function disabled |
|
11 | LED frame – colour when ON | This parameter defines the LED colour when thedevice is ON. When set to 8 or 9, LED frame colour will change depending on he measured power and parameter 10. Other colours are set permanently and do not depend on power consumption. | 0 | 1 | 0 | 0 | 1 | From | To | Description |
|---|
0 | 0 | LED disabled | 1 | 1 | White | 2 | 2 | Red | 3 | 3 | Green | 4 | 4 | Blue | 5 | 5 | Yellow | 6 | 6 | Cyan | 7 | 7 | Magenta | 8 | 8 | colour changes smoothly depending on measured power | 9 | 9 | colour changes in steps depending on measured power |
|
25 | Outputs orientation | This parameter allows reversing the operation of Q1 and Q2 without changing the wiring (e.g. in case of invalid connection). Changing orientation turns both outputs off. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
0 | 0 | default (Q1 - 1st channel, Q2 - 2nd channel) | 1 | 1 | reversed (Q1 - 2nd channel, Q2 - 1st channel) |
|
155 | Second channel - time parameter for delayed OFF / pulse modes | This parameter allows to set time parameter used in timed modes for 2nd channel (parameter 151). Delay time for switching off or duration of the pulse. | 0 | 2 | 0 | 0 | 50 | From | To | Description |
|---|
0 | 0 | 0.1 second | 1 | 32000 | (1-32000s, 1s step) – time parameter |
|
31 | Alarm configuration - 2nd slot | This parameter determines to which alarm frames and how the device should react. The parameters consist of 4 bytes, three most significant bytes are set according to the official Z-Wave protocol specification. | 0 | 4 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | [MSB] – Notification Type | 2 | 2 | Notification Value | 3 | 3 | Event/State Parameters | 4 | 4 | [LSB] – action |
|
41 | Second button – scenes sent | This parameter determines which actions result in sending scene IDs assigned to them. Values can be combined (e.g. 1+2=3 means that scenes for single and double click are sent). Enabling scenes for triple click disables entering the device in learn mode by triple clicking. | 0 | 1 | 0 | 0 | 0 | From | To | Description |
|---|
1 | 1 | Key pressed 1 time | 2 | 2 | Key pressed 2 time | 4 | 4 | Key pressed 3 time | 8 | 8 | Key hold down and key released |
|
