COMMAND_CLASS_CONFIGURATION_V4

Configuration V4

0x70

4

COMMAND_CLASS_SWITCH_BINARY_V2

Switch Binary V2

0x25

2

COMMAND_CLASS_POWERLEVEL

Powerlevel

0x73

1

COMMAND_CLASS_ASSOCIATION_V3

Association V3

0

COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V3

Multi-Channel Association V3

0x8E

3

COMMAND_CLASS_INDICATOR_V3

Indicator V3

0x87

3

COMMAND_CLASS_TRANSPORT_SERVICE_V2

Transport Service V2

0x55

2

COMMAND_CLASS_DEVICE_RESET_LOCALLY

Device Reset Locally

0x5A

1

COMMAND_CLASS_ZWAVEPLUS_INFO_V2

Z-Wave Plus Info V2

0x5E

2

COMMAND_CLASS_FIRMWARE_UPDATE_MD_V5

Firmware Update Meta-Data V5

0x7A

5

COMMAND_CLASS_ASSOCIATION_GRP_INFO_V3

Association Group Information V3

0x59

3

COMMAND_CLASS_BASIC_V2

Basic V2

0x20

2

COMMAND_CLASS_SECURITY_2

Security S2

0x9F

1

COMMAND_CLASS_MANUFACTURER_SPECIFIC

Manufacturer Specific

0x72

1

COMMAND_CLASS_VERSION_V3

Version V3

0x86

3

COMMAND_CLASS_CENTRAL_SCENE_V3

Central Scene V3

0x5B

3

COMMAND_CLASS_SUPERVISION

Supervision

0x6C

1

Manual_Primary_Lang

Product Manual

Installer_Guide

Installation Guide

Color

Firmware Updatable

Switch Type

1

1

0

Lifeline

Z-Wave Lifeline

3

5

0

BASIC SET

Send BASIC SET Command

2

5

0

BASIC SET

Send BASIC SET Command

1

KeyFunction

Parameter=1，Size=1， Value=0 Up Button: On Down Button: Off Value=1 Up Button: Off Down Button: On Value=2 Up Button: On/Off Down Button: On/Off

2

1

0

2

0

2

LED Indicator

Parameter=2，Size=1 Value=0 On when Off and Off when On Value=1 On when On and Off when Off Value=2 Always Off Value=3 Always On

2

1

0

3

0

3

Auto Turn-Off Timer

Parameter=3，Size=4， Value=0 timer disabled (default);  Values: 1 – 65535 (minutes);

2

4

0

65535

0

5

Auto Turn-On Timer

Parameter=5，Size=1， Value=0 timer disabled (default);  Values: 1 – 65535 (minutes);

2

4

0

65535

0

8

Restores state after power failure

Parameter=8，Size=1， Value=0 output off Value=1 output on Value=2 out put the state after power

2

1

0

2

2

9

Enable or Disable Scene

Parameter=9，Size=1， Value=0 disable Value=1 enable

2

1

0

1

0

11

Enable or Disable OutPut control

Parameter=11，Size=1，Value=0 disable local button and External Switch control enable Z-Wave control Value=1 enable local button and External Switch control enable Z-Wave control Value = 2 disable local button and External Switch control

2

1

0

2

1

5

Factory Reset Procedure

:Press and hold lower paddle for 10 seconds, then LED starts blinking, release paddle and within 2 seconds, click lower paddle 5 times (Node:Please use this procedure only when the network primary controller is missing or otherwise inoperable.)

8

Where to find S2 DSK on product

The device is compatible with SmartStart SmartStart enabled products can be added into a Z-Wave™ network by scanning the Z-Wave QR Code found on the top of the outlet or the back of the box with a controller providing SmartStart inclusion.No further action is required and the SmartStart product will be added automatically within 10 minutes of being switched on and in the network vicinity. the QR code are sticked to the side of the case,DSK is included in the QR code. The DSK code can be found on the DSK label which is attached on the packaging box.

1

Classic Inclusion

The device support two methods of inclusion,When using a Z-Wave Plus™ certified controller choose Network Wide Inclusion or SmartStart, Network Wide Inclusion To A Z-Wave™ Network 1,Refer to your primary controller instructions to process the inclusion / exclusion setup procedure. 2,When prompted by your primary controller, click the Up or Down button three times in one second.

2

Classic Exclusion

The device support two methods of inclusion,When using a Z-Wave Plus™ certified controller choose Network Wide Inclusion or SmartStart, Network Wide Inclusion To A Z-Wave™ Network 1,Refer to your primary controller instructions to process the inclusion / exclusion setup procedure. 2,When prompted by your primary controller, click the Up or Down button three times in one second.
